Infrastructure
|
Installed Machinery Details |
||||||||
|
CNC Lathe / Turn Mill |
||||||||
|
Sl. No. |
Machine Make & Model |
Controller |
Swing Over Bed (mm) |
Max. Turning Dia. (mm) |
Max. Turning Length (mm) |
Spindle Speed (RPM) |
Spindle Power (kw) |
Remarks |
|
1 |
LEADWELL LTC20B |
Siemens |
450 |
320 |
500 |
4000 |
15 |
Turning Centre |
|
2 |
LEADWELL LTC20B |
Fanuc |
450 |
320 |
500 |
4000 |
15 |
Turning Centre |
|
3 |
ACE DESIGNERS JOBBER LM |
Fanuc |
500 |
225 |
425 |
4000 |
8.4 |
Turning Centre |
|
4 |
ACE DESIGNERS JOBBER LM |
Siemens |
500 |
225 |
425 |
4000 |
8.4 |
Turning Centre |
|
5 |
ARIX NCL 42 |
ARIX |
200 |
150 |
220 |
6000 |
5 |
Turning Centre |
|
6 |
ARIX NCL 30 |
ARIX |
150 |
130 |
220 |
6000 |
5 |
Turning Centre |
|
7 |
HYUNDAI E160A |
Fanuc |
200 |
190 |
200 |
4000 |
7.5 |
Turning Centre |
|
8 |
ACE DESIGNERS APOLLO |
Fanuc |
200 |
190 |
200 |
4000 |
3.7 |
Turning Centre |
|
9 |
SGS 135 |
Fanuc |
200 |
190 |
200 |
3000 |
2.3 |
Turning Centre |
|
10 |
ARIX TMD42 |
ARIX |
200 |
130 |
160 |
4000 |
7.5 |
Turn Mill |
|
11 |
ARIX TMS42 |
ARIX |
200 |
130 |
160 |
4000 |
7.5 |
Turn Mill |
|
CNC VMC |
||||||||
|
Sl. No. |
Machine Make & Model |
Controller |
Table Size (mm) |
Stroke X – Y – Z (mm) |
Tool (nos) |
Spindle Speed (RPM) |
Spindle Power (kw) |
Remarks |
|
1 |
LEADWELL V42i |
Fanuc |
1100 x 500 |
1000 x 510 x 610 |
24 |
8000 |
11 |
4 Axis VMC |
|
2 |
LEADWELL V40 |
Siemens |
1200 x 500 |
1000 x 510 x 610 |
24 |
10000 |
18.5 |
4 Axis VMC |
|
3 |
FULLAND GLG360 |
Mitsubishi |
960 x 500 |
860 x 510 x 500 |
24 |
8000 |
7.5 |
4 Axis VMC |
|
4 |
YOUJI VMC850 |
Fanuc |
1000 x 550 |
850 x 600 x 600 |
24 |
8000 |
11 |
4 Axis VMC |
|
5 |
LEADWELL V30 |
Fanuc |
890 x 500 |
800 x 510 x 610 |
24 |
8000 |
11 |
3 Axis VMC |
|
6 |
MILL STAR LMV760APC |
Fanuc |
760 x 420 |
710 x 460 x 460 |
24 |
10000 |
5.5 |
3 Axis VMC |
|
7 |
ARIX V-700 |
ARIX |
700 x 500 |
700 x 500 x 450 |
24 |
10000 |
7.5 |
4 Axis VMC |
|
8 |
SUNMILL JHV550 |
Fanuc |
650 x 410 |
550 x 410 x 460 |
24 |
10000 |
5.5 |
4 Axis VMC |
|
CNC HMC |
||||||||
|
Sl. No. |
Machine Make & Model |
Controller |
Table Size (mm) |
Stroke X – Y – Z (mm) |
ATC (nos) |
Spindle Speed (RPM) |
Spindle Power (kw) |
Remarks |
|
1 |
MITSUBISHI M-H4B |
Mitsubishi |
400 x 400 |
285 x 560 x 650 |
60 |
12000 |
22 |
HMC |
|
CNC VTL |
||||||||
|
Sl. No. |
Machine Make & Model |
Swing Over Bed (mm) |
Max. Turning Dia. (mm) |
Max. Turning Length (mm) |
Spindle Speed (RPM) |
Spindle Power (kw) |
Remarks |
|
|
1 |
TONGTAI TVL30-S2 |
Fanuc |
560 |
520 |
350 |
600 |
22 |
VTL |
|
2 |
TONGTAI TVL30-S2 |
Fanuc |
700 |
520 |
450 |
600 |
22 |
VTL |
|
CMM |
||||||||
|
Sl. No. |
Machine Make & Model |
Table Size (mm) |
Range (mm) |
Accuracy (mm) |
Remarks |
|||
|
1 |
GMT |
1700 x 950 |
750 x 1000 x 550 |
0.001 |
CMM |
|||
|
Grinding |
||||||||
|
Sl. No. |
Machine Make & Model |
Specification |
Remarks |
|||||
|
1 |
JAINNHER JHC-18S |
20 to 40 mm Dia |
Centerless Grinding |
|||||
